CM300  Main Advantages:

1. Supports 3-axis RTCP simultaneous interpolation;

2. Supports multi-card mode, enabling collaborative control of multiple cards using extended G-code;

3. Supports in-depth user configuration and rapid secondary development of the interface; automatic deployment of functional components;

4. Supports 3D dynamic machining simulation;

5. Enables bidirectional positioning of tool paths and G-code;

6. Supports Modbus bus protocol;

7. Powerful pre-reading processing capability of 30,000 lines, supporting path look-ahead planning;

8. Smooth processing of small line segments, resulting in better surface quality and higher efficiency;

9. Supports custom macro programs;

10. Supports handwheel guidance; all movements can be guided by the handwheel, such as homing, tool setting, and tool magazine operation;

11. Supports rotary, linear, and non-standard tool magazine extensions;

12. Supports advanced CAM machining functions such as face milling;

13. Supports fixed tool setting, floating tool setting, automatic centering detection, and customizable detection functions;

14. Supports custom G-code, servo spindle, and rigid tapping;

15. Supports custom function shortcut keys; general input ports can be configured as shortcut function keys;

16. Supports multiple machining strategies, including array machining, single-segment machining, cyclic machining, and nearest-point machining;

17. Supports axis mapping;

18. Supports rotary axis encoders;

19. Supports large machining files up to 4GB;

20. Supports multiple system platforms, including Windows and Android;

Application areas: Engraving machines, mold machines, machining centers, precision engraving machines, automated assembly line equipment, etc.
